HP Z6 G4 Workstation
| Storage type | SSD, HDD |
| Storage Size | 512 GB, 1TB |
| Brand | HP |
| Operating System | Windows 10 Pro |
| Processor Make | Intel |
| Processor Series | Xeon |
| Processor Model | Gold-Series |
| Memory Type | DDR4 |
| Memory Size | 64 GB |
| Graphics Make | NVIDIA |
| Graphic Series | Quadro |
| Graphics Model | K2200 |
Product Description
Specification
| Brand | HP |
| Model | HP Z6 G4 |
Product Type
| Product type | Workstation |
Form Factor
| Form Factor | Mid-Tower |
Processor
| CPU Information | Single Intel Xeon Gold 6134 3.2 GHz 24.75 MB cache and 8 cores Up to 3.7 GHz with Intel Turbo Boost Technology Supports DDR4 memory up to 2666 MT/s data rate 130 W Supports Intel vPro technology Intel® Xeon® processor Scalable family Intel® Xeon® W-3200 Series Intel® Xeon® W-3275 2.5 2933 28C processor Intel® Xeon® W-3265 2.7 2933 24C processor Intel® Xeon® W-3245 3.2 2933 16C processor Intel® Xeon® W-3235 3.3 2933 12C processor Intel® Xeon® W-3225 3.7 2666 8C processor Intel® Xeon® W-3223 3.5 2666 8C processor Intel® Xeon® Scalable CPU Intel® Xeon® Gold 6258R processor Intel® Xeon® Gold 6248R processor Intel® Xeon® Gold 6246R processor Intel® Xeon® Gold 6244 processor 5YT05AA Intel® Xeon® Gold 6242R processor Intel® Xeon® Gold 6242 processor 5YT04AA Intel® Xeon® Gold 6240R processor Intel® Xeon® Gold 6240 processor 5YT02AA Intel® Xeon® Gold 6238R processor Intel® Xeon® Gold 6234 processor 5YT00AA Intel® Xeon® Gold 6230R processor 9VA87AA Intel® Xeon® Gold 6226R processor 9VA85AA Intel® Xeon® Gold 6226 processor 5YS98AA Intel® Xeon® Gold 6136 processor 1XM39AA Intel® Xeon® Gold 6128 processor 1XM44AA Intel® Xeon® Gold 5222 processor 5YS97AA Intel® Xeon® Gold 5220R processor 8BC99AA/AT Intel® Xeon® Gold 5218R processor9VA83AA Intel® Xeon® Gold 5218 processor 5YS95AA Intel® Xeon® Gold 5215 processor 5YS94AA Intel® Xeon® Gold 5118 processor 1XM45AA Intel® Xeon® Silver 4216 processor 5YS93AA Intel® Xeon® Silver 4215R processor 9VA81AA Intel® Xeon® Silver 4214R processor 8BC96AA/AT Intel® Xeon® Silver 4214 processor 5YS91AA Intel® Xeon® Silver 4210R processor 8BC95AA Intel® Xeon® Silver 4210 processor 5YS90AA Intel® Xeon® Silver 4208 processor 5YS89AA Intel® Xeon® Silver 4114 processor 1XM49AA Intel® Xeon® Silver 4108 processor 1XM51AA Intel® Xeon® Bronze 3206R processor 8BC93AA Intel® Xeon® Bronze 3204 processor Y Y 5YS88AA |
Memory
| Installed Memory | 64GB DDR4 |
| Memory Type | DDR4-2666 registered DIMMs. Supported Rams DDR4-2666 ECC Registered DIMMs (1) CPU memory HP 8GB (8 GB x 1) DDR4-2666 ECC Reg RAM 16 GB (8 GB x 2) DDR4-2666 ECC Reg RAM 24 GB (8 GB x 3) DDR4-2666 ECC Reg RAM 32 GB (8 GB x 4) DDR4-2666 ECC Reg RAM 48 GB (8 GB x 6) DDR4-2666 ECC Reg RAM HP 16GB (16 GB x 1) DDR4-2666 ECC Reg RAM 32 GB (16 GB x 2) DDR4-2666 ECC Reg RAM 48 GB (16 GB x 3) DDR4-2666 ECC Reg RAM 64 GB (16 GB x 4) DDR4-2666 ECC Reg RAM 96 GB (16 GB x 6) DDR4-2666 ECC Reg RAM HP 32GB (32 GB x 1) DDR4-2666 ECC Reg RAM 64 GB (32 GB x 2) DDR4-2666 ECC Reg RAM 96 GB (32 GB x 3) DDR4-2666 ECC Reg RAM 128 GB (32 GB x 4) DDR4-2666 ECC Reg RAM 192 GB (32 GB x 6) DDR4-2666 ECC Reg RAM (2) CPU memory 32 GB (8 GB x 4) DDR4-2666 ECC Reg RAM 48 GB (8 GB x 6) DDR4-2666 ECC Reg RAM 64 GB (8 GB x 8) DDR4-2666 ECC Reg RAM 96 GB (8 GB x 12) DDR4-2666 ECC Reg RAM 64 GB (16 GB x 4) DDR4-2666 ECC Reg RAM 96 GB (16 GB x 6) DDR4-2666 ECC Reg RAM 128 GB (16 GB x 8) DDR4-2666 ECC Reg RAM 192 GB (16 GB x 12) DDR4-2666 ECC Reg RAM 128 GB (32 GB x 4) DDR4-2666 ECC Reg RAM 192 GB (32 GB x 6) DDR4-2666 ECC Reg RAM 256 GB (32 GB x 8) DDR4-2666 ECC Reg RAM 384 GB (32 GB x 12) DDR4-2666 ECC Reg RAM Maximum Supports up to 384GB with two processors |
Hard Disk
| Storage Option | Serial Attached SCSI (SAS) Hard drive HP 300GB 15K SAS SFF Hard Drive (controller add-in card required) SATA Hard Disk Drive (HDD) HP 500GB SATA 6Gb/s 7200 Hard Drive HP 500GB 7200rpm SATA SFF SED Hard Drive HP 1TB SATA 6Gb/s 7200 Hard Drive HP 1TB Enterprise SATA 7200 HDD HP 2TB SATA 6Gb/s 7200 Hard Drive HP 4TB SATA 7200 Hard Drive NOTE: Up to (4) 8.89 cm (3.5 in) 7200 rpm SATA drives 500 GB, 1.0, 2.0, 4.0 TB 16 TB maximum total SATA Solid State Drives (SSD) HP 256GB SATA SSD HP 512GB SATA SSD HP 1TB SATA SSD HP 2TB SATA SSD HP 256GB SATA SED Opal2 Solid State Drive HP 512GB SATA SED Opal2 Solid State Drive HP Enterprise Class 240GB SATA SSD HP Enterprise Class 480GB SATA SSD PCIe Solid State Drives (SSD) HP Z Turbo Drive 256GB MLC (Z4/Z6 G4) SSD Kit HP Z Turbo Drive 512GB MLC (Z4/Z6 G4) SSD Kit HP Z Turbo Drive 1TB MLC (Z4/Z6 G4) SSD Kit HP Z Turbo Drive 256GB TLC (Z4/Z6 G4) SSD Kit HP Z Turbo Drive 512GB TLC (Z4/Z6 G4) SSD Kit HP Z Turbo Drive 1TB TLC (Z4/Z6 G4) SSD Kit HP Z Turbo Drive 256GB SED (Z4/Z6 G4) SSD Kit HP Z Turbo Drive 512GB SED (Z4/Z6 G4) SSD Kit HP Z Turbo Drive Quad Pro HP Z Turbo Drive Quad Pro 2x256GB PCIe SSD HP Z Turbo Drive Quad Pro 2x512GB PCIe SSD HP Z Turbo Drive Quad Pro 2x1TB PCIe SSD NOTE: Dual M.2 SSD modules plus the carrier. HP Z Turbo Drive Quad Pro 256GB SSD module HP Z Turbo Drive Quad Pro 512GB SSD module HP Z Turbo Drive Quad Pro 1TB SSD module NOTE: M.2 SSD modules only that are designed to be installed into the Quad Pro carrier. On-board RAID support SATA RAID 0 Striped array configuration SATA RAID 1 Mirrored array configuration SATA RAID 10 Striped/mirrored array configuration SATA RAID 5 Parity array configuration |
| Installed Hard Disk | HDD 3.5 |
GRAPHICS CONTROLLER
| Display Adapter | Installed Graphic Card Nvidia Quadro K2200 4GB (GDDR5) Supported Graphic Cards Entry 3D NVIDIA Quadro P400 2GB Graphics NVIDIA Quadro P600 2GB Graphics AMD FirePro W2100 2GB Graphics NOTE: Two graphic cards supported. Mid-range 3D NVIDIA Quadro P1000 4GB Graphics NVIDIA Quadro P2000 5GB Graphics AMD Radeon Pro WX 3100 4GB Graphics AMD Radeon Pro WX 4100 4GB Graphics Supports AMD Enduro Technology Microsoft DirectX 12 (Shader Model 5.0) and OpenGL 4.3 are capable NOTE: Two graphic cards supported. High-End 3D Radeon Pro WX7100 8GB Graphics NVIDIA Quadro P4000 8GB Graphics NVIDIA Quadro P5000 16GB Graphics NOTE: Two graphic cards supported. NVIDIA Quadro P6000 24GB Graphics NOTE: Single graphics card supported. 1000 W chassis. |
EXPANSION / CONNECTIVITY
| Expansion Slots | Input/output ports Front I/O (standard) (4) USB 3.1 Gen 1 Type-A (1 charging) (1) Headset audio port Front I/O (optional premium) (2) USB 3.1 Gen 1 Type-A connector (1 charging) (2) USB 3.1 Gen 2 Type-C connector (1) Combo headset (1) Optional media card reader Internal I/O (1) USB 3.1 Gen 1 (aka USB 3.0) single-port header (1) USB 2.0 single-port header (1) USB 2.0 dual-port header Rear I/O (6) USB 3.1 Gen 1 (aka USB 3.0) Type-A ports (2) 1 Gbe LAN ports (1x supporting Intel AMT) (1) Audio line-out (1) Audi line-in (line-in can be retasked as a microphone) (1) PS/2 mouse (1) PS/2 keyboard Expansion slots Slot 0 (mechanical only) Only for rear bulkhead mounting or when 2nd CPU riser is installed Slot 1 PCI Express Gen 3 x4 - CPU with open-ended connector Slot 2 PCI Express Gen 3 x16 - CPU Slot 3 PCI Express Gen 3 x4 - PCH with open-ended connector Slot 4 PCI Express Gen 3 x8 – CPU with open-ended connector NOTE: Slot converts to x4 electrical when SSD is installed in 2nd M.2 slot. Slot 5 PCI Express Gen 3 x16 - CPU Slot 6 PCI Express Gen3 x4 - PCH with open-ended connector M.2 Slot 1 M.2 PCIe Gen 3 x4 - CPU up to 80 mm (3.15 in) storage devices M.2 Slot 2 M.2 PCIe Gen 3 x4 - CPU up to 80 mm (3.15 in) storage devices Expansion bays (2) Internal 8.89 cm (3.5 in) bays (2) External 13.33 cm (5.25 in) bays (1) 9.5 mm (0.37 in) slim optical disk drive bay |
NETWORKING
| Ports | Integrated one Gigabit Ethernet (Intel i218LM), supports Wake-on-LAN |
POWER
| Power Options | Power supply 1000 W/100 V/15 A 90% Efficient wide-ranging, active Power Factor Correction (PFC) Includes 2x 6-pin graphics power cables (graphics power cables are 6/8-pin convertible |
DIMENSIONS & WEIGHT
| dimensions ( H x W x D) | H: 17.5" (445mm) W: 6.65" (169mm) D: 18.3" (465mm) |
| Weight | Minimum: 13.1 kg (29 lbs.) Standard: 13.6 kg (30.1 lbs.) Maximum: 23.9 kg (52.7 lbs.) |
OPERATING SYSTEM
| Pre Install Os | OS Provided: Windows 10 Pro |
